Watanabe Digital Panel Meters TZ-5XA-22H
āļāļģāļāļāļīāļāļēāļĒāļŠāļīāļāļāđāļēāđāļāļāļĒāđāļ
Digital Panel Meters TZ-5XA-22H
āđāļāļĢāļāļāđ: Watanabe
āļŦāļĄāļ§āļāļŦāļĄāļđāđ:
āļāļĢāļ°āđāļ āļāļŠāļīāļāļāđāļē,
Instruments & Controls,
Measurement,
Watanabe,
Others
Product description
Model : TZ-5XA-22H
TZ-5XA : Series
-
2 : Input Code, 0 to 10VDC
2 : Output Code, 0 to 10VDC
H : Response Time, 1msec
General Specification :-
Base Accuracy : ¹0.1 %F.S (At 25¹2°C)
Power Supply Variation : Âą0.06 %F.S
Load Resistance Variation : Âą0.06 %F.S
Temperature Characteristic : ¹0.02 %F.S/°C
Response Time : Less than 50 msec (TYP)(0 - 90%)
Front Adjustments : Âą5% For Zero And Span
Insulation Resistance : Between Input and Output/Power Supply;
More than 100M Ohms at 500 VDC
Dielectric Strength : Between Input and Output/Power Supply;
For 1 min. at 1500 VDC
Power Supply Voltage : 24 VDC Âą10%
Consuming Current : Less than 30 mA (24VDC at Voltage Output)
Operating Ambient Temperature : -5 to 50°C
Operating Ambient Humidity : Less than 90%RH (No-condensing)
Storage Temperature : -10 to 70°C
Storage Humidity : Less than 60%RH (No-condensing)
Case Material : ABS Resin (Black) 94V-2
Weight : Approx. 80g
Vibration Resistance : Frequency : 10 to 55Hz
: Amplitude (half) : 0.15mm to 10 Sweeps of 5 min
each in X, Y, and Z Directions
TZ-5XA : Series
-
2 : Input Code, 0 to 10VDC
2 : Output Code, 0 to 10VDC
H : Response Time, 1msec
General Specification :-
Base Accuracy : ¹0.1 %F.S (At 25¹2°C)
Power Supply Variation : Âą0.06 %F.S
Load Resistance Variation : Âą0.06 %F.S
Temperature Characteristic : ¹0.02 %F.S/°C
Response Time : Less than 50 msec (TYP)(0 - 90%)
Front Adjustments : Âą5% For Zero And Span
Insulation Resistance : Between Input and Output/Power Supply;
More than 100M Ohms at 500 VDC
Dielectric Strength : Between Input and Output/Power Supply;
For 1 min. at 1500 VDC
Power Supply Voltage : 24 VDC Âą10%
Consuming Current : Less than 30 mA (24VDC at Voltage Output)
Operating Ambient Temperature : -5 to 50°C
Operating Ambient Humidity : Less than 90%RH (No-condensing)
Storage Temperature : -10 to 70°C
Storage Humidity : Less than 60%RH (No-condensing)
Case Material : ABS Resin (Black) 94V-2
Weight : Approx. 80g
Vibration Resistance : Frequency : 10 to 55Hz
: Amplitude (half) : 0.15mm to 10 Sweeps of 5 min
each in X, Y, and Z Directions
