Manostar Low Differential Pressure Gauge WO81FN+-500D
Low Differential Pressure Gauge WO81FN+-500D
หมวดหมู่ :
ประเภทสินค้า
,
Instruments & Controls
,
Measurement
,
Manostar
,
Pressure Gauge
,
Manostar
,
Others
แบรนด์ :Manostar
Product description
WO81 :- Series
F :- Surface Mount
N :- None Fixed Indicator
+-500D :- Range Code
- Display Range : 0 to ±500 Pa
- Standard Installation Position : Free Position (Horizontal or Vertical)
- Accuracy at 20°C : Up to ± 1.5% F.S.
- Diaphragm Material : Silicone Rubber
- Diaphragm Pressure Resistance : 40 kPa
- Gases Measured : Air & Non-Corrosive Gases (No Liquid)
- Orientation of Connectors : High Pressure Side (Red), Low Pressure Side (Blue)
- Weight : Approx. 270g
F :- Surface Mount
N :- None Fixed Indicator
+-500D :- Range Code
- Display Range : 0 to ±500 Pa
- Standard Installation Position : Free Position (Horizontal or Vertical)
- Accuracy at 20°C : Up to ± 1.5% F.S.
- Diaphragm Material : Silicone Rubber
- Diaphragm Pressure Resistance : 40 kPa
- Gases Measured : Air & Non-Corrosive Gases (No Liquid)
- Orientation of Connectors : High Pressure Side (Red), Low Pressure Side (Blue)
- Weight : Approx. 270g
